When you need reliable signal termination for your RF systems, the TNC RF Coaxial Load delivers exceptional performance across a wide frequency spectrum. This precision-engineered component provides your test setups and communication systems with stable 50-ohm impedance termination. Whether you're working on laboratory measurements or field applications, our product ensures consistent signal integrity from DC to 18GHz. The robust threaded connection mechanism offers superior reliability compared to other connector types. You can trust this load termination to maintain performance even in demanding environments.
Our load termination offers low VSWR and consistent performance across frequencies, minimizing signal reflections from RF to microwave spectrum.
The strung association plan guarantees steadiness beneath stun and vibration, making it perfect for aviation, defense, and mechanical applications.
Operating dependably from -55°C to 125°C, this component handles extraordinary temperature varieties without execution debasement. The carefully chosen materials guarantee warm solidness over the full temperature range.
| Parameter | Specification |
|---|---|
| Product Name | TNC-JR-18-10W RF Load |
| Impedance | 50 Ohms nominal |
| Frequency Range | DC to 18GHz |
| Temperature Range | -55°C to 125°C |
| Parameter | Value |
|---|---|
| VSWR | 1.25:1 to 18GHz typical |
| Insertion Loss | .1 √f (GHz) |
| Power Rating | 10W |
| Dielectric Withstand Voltage | 1000 Vrms @ sea level |
| Insulation Resistance | 5,000 megohms minimum |
| Contact Resistance (Outer) | 0.3 milliohms maximum |
| Contact Resistance (Inner) | 1 milliohms maximum |
| Component | Material |
|---|---|
| Housing | Nickel-plated brass |
| Center Contacts | Beryllium copper gold |
| Insulators | PTFE |
| Parameter | Specification |
|---|---|
| Mate/Demate Cycles | 500 cycles |
| Engagement/Disengagement Force | ≤0.23N·m |
| Connection Torque | 0.79N·m - 1.13N·m |
| Connector Withstand Torque | 1.2N·m |
This load termination provides stable impedance, ensuring accurate, repeatable measurements in calibration setups and network analyzer testing.
This component ensures proper termination, reducing interference and improving signal quality for optimal RF system performance.
The rugged construction meets demanding environmental requirements found in defense applications. You get reliable performance in extreme conditions where failure is not an option. The TNC RF Coaxial Load maintains specifications through temperature cycling, vibration, and shock conditions.
This load termination provides stable reference impedance, ensuring reliable testing and validation for efficient RF product development.
The component meets stringent environmental testing standards:
We specialize in precision RF components with expertise in high-frequency and millimeter wave technology up to 110GHz. Located in Xi'an's Chang'an Park, we deliver quality solutions with strict manufacturing quality control. Our precision testing instruments ensure every component meets specifications before shipment. You receive products that perform reliably from the moment of installation.
Proper installation with specified torque values ensures secure connections and optimal performance. The threaded interface provides tactile feedback for proper engagement. Consider power dissipation requirements when integrating this load termination into your system. The 10W power rating accommodates most laboratory and field applications while maintaining temperature specifications.
For technical support, custom specifications, or ordering information, reach out to our engineering team. We're ready to help you select the right components for your specific application requirements.
Email: postmaster@cymicrowave.com
Our experienced engineers can assist with custom solutions when standard products like TNC RF Coaxial Load don't meet your exact needs. We understand that each application has unique requirements and we're equipped to deliver tailored solutions.
