Name: Battery Testing Fixture
SKU: N/A

Battery Testing Fixture

1. A specialized tool for battery forming and performance testing during the production process of soft pack lithium batteries, belonging to the field of lithium battery production technology, suitable for online detection during large-scale production of soft pack lithium batteries.
2. Low resistance probe, typical Ri value: < 0.2 milliohms. Supports four-terminal measurement up to 300A (customizable).
3. Material: Gold-plated copper, high-temperature resistant plastic
4. Dimensions: 100*72*113mm
5. Operating temperature: -45°C to +80°C.

Battery Testing Fixture - Precision Testing Solutions for Lithium Battery Production

When you're developing lithium batteries at scale, precision testing becomes absolutely critical to your success. Our Battery Testing Fixture represents years of engineering expertise designed specifically for soft-pack lithium battery production lines. You need reliable, accurate testing tools that can handle high-current applications while maintaining exceptional precision. That's exactly what our specialized fixture delivers. Whether you're working with PERC, HPBC, or TOPCon advances, this testing arrangement guarantees your batteries meet the most elevated quality benchmarks. The installation combines low-resistance examining capabilities with temperature detecting usefulness, making it an fundamental component for your generation workflow.

Battery Testing Fixture

Why Select Our Battery Testing Solutions?

Superior Execution in Requesting Environments

Our testing installations highlight ultra-low resistance tests (Ri < 0.2 milliohms) for exact high-current testing (up to 300A). Gold-plated copper guarantees erosion resistance and steady execution from -45°C to +80°C, advertising long-term unwavering quality in differing conditions.

Modular Design for Maximum Flexibility

Our modular testing solutions allow on-demand expansion without system overhaul. Compact, lightweight design and versatile connection options ensure easy integration and reduced mechanical stress.

Advanced Contact Technology

Our Battery Testing Fixture incorporates beryllium copper gold plungers that provide exceptional durability and conductivity. The four-terminal measurement capability eliminates contact resistance errors that could compromise your test accuracy.

Temperature sensing functionality adds another layer of quality control to your process. You can monitor thermal conditions during testing to ensure optimal battery performance characteristics.

Battery Testing Fixture

Technical Specifications

General Specifications	Values
Model	CYSPJ 300A-114
Operating Temperature	-45°C to +80°C
Dimensions	100×72×113mm
Weight	0.55kg
Number of Channels	1CH
Mechanical Data	Specifications
--------------------	-------------------
Nose Size	M4/M10
Current Screw	M10×12
Voltage Screw	M4×6
Flame Retardant Rating	UL94V-0
Electrical Performance	Values
---------------------------	------------
Current Load Capacity	300A@30℃
Typical Resistance (Ri)	<0.2 mOhm
Plunger Material	Beryllium Copper Gold

Applications Across Battery Technologies

Soft-Pack Lithium Battery Production

Your soft-pack lithium battery lines require specialized testing equipment that can adapt to flexible battery shapes. Our fixtures excel in these applications, providing reliable contact even with irregular surfaces.

The hot-pressing module compatibility makes these fixtures ideal for formation and grading processes where thermal control is essential.

High-Volume Manufacturing Integration

Our testing solutions ensure consistent results, seamlessly integrate with automated lines, and provide reliable, continuous quality monitoring without disrupting throughput, even in demanding environments.

Quality Assurance and Reliability

Precision Manufacturing Standards

At Shaanxi Chuangyu Electronic Technology, we maintain strict production process management and utilize precision testing instruments throughout manufacturing. This approach ensures every Battery Testing Fixture meets exacting specifications before reaching your facility.

Our digital manufacturing processes eliminate variability, giving you consistent performance across all units.

Extended Service Life

Our testing items final over 5 million cycles, lessening upkeep costs and minimizing interferences. Gold-plated surfaces stand up to oxidation, guaranteeing moo contact resistance all through the fixture's life.

Battery Testing Fixture

Customization Capabilities

Tailored Arrangements for Special Requirements

We recognize that standard arrangements do not continuously meet each application's needs. Our designing group can customize different perspectives of the item to coordinate your particular requirements.

Whether you require distinctive current evaluations, elective association strategies, or specialized natural details, we can adjust our plans accordingly.

Future-Ready Technology

We're committed to advancement, creating unused arrangements and growing associations in economical battery advances. Our forward-thinking approach guarantees your speculation in testing arrangements remains profitable as innovation advances.

Battery Testing Fixture

Getting Started with Our Testing Solutions

Ready to enhance your battery testing capabilities with the Battery Testing Fixture? Our team stands ready to discuss your specific requirements and recommend the optimal configuration for your production line.

Contact us at postmaster@cymicrowave.com to explore how our precision testing fixtures can improve your quality control processes. We'll help identify the best solution for your battery testing challenges, ensuring seamless integration. Rely on our expertise for reliable, accurate testing to meet your quality standards.
