Name: SSMA Detachable Connector
SKU: N/A

SSMA Detachable Connector

1. The SSMA separable connector is a miniature RF coaxial connector, serving as the compact version of the SMA series. It is commonly used for high-frequency signal transmission applications and offers various configurations, such as cable connections, panel mounting, and adapters. The connector supports customization requirements (e.g., size and specification customization).
2. The connector tail adapts to pins such as 0.38, 0.51, etc.
3. Impedance: 50 Ohms nominal
4. VSWR: 1.25:1 up to 26.5GHz typical
5. Insertion loss: .05√f (GHz)
6. Temperature range: -55°C to 125°C

Professional SSMA Detachable Connector for Precision Applications

Are you looking for a reliable miniature RF coaxial connector for your high-frequency projects? Our SSMA Detachable Connector delivers exceptional performance in a compact design. This connector serves as the smaller than expected adaptation of the standard SMA arrangement, making it culminate for space-constrained applications. Whether you require cable associations, board mounting, or connector setups, our SSMA connector meets your requesting necessities with accuracy and reliability.

product-1-1

What Makes Our SSMA Connectors Stand Out?

Compact However Capable Design

Our connectors offer compact measure and strong execution, guaranteeing fabulous flag keenness without compromising space, making them perfect for versatile hardware, broadcast communications, and aviation applications.

Superior Material Construction

We use premium materials to ensure long-lasting performance:

Stainless steel housings with passivation for corrosion resistance
Beryllium copper gold center contacts for optimal conductivity
PTFE insulators for excellent dielectric properties

Versatile Configuration Options

Your projects have unique requirements. That's why we offer multiple configuration options including cable connections, panel mounting solutions, and various adapter types. We also provide customization services to meet your specific size and specification needs.

product-1-1

Technical Specifications

Parameter	Specification
Impedance	50 Ohms nominal
Frequency Range	DC to 18GHz
Temperature Range	-55°C to 125°C
VSWR	1.25:1 to 18GHz typical
Insertion Loss	.05√f (GHz)
Mate/Demate Cycles	500 cycles
DWV @ Sea Level	750 Vrms
Insulation Resistance	5,000 megohms minimum
Contact Resistance (Outer)	2.5 milliohms maximum
Contact Resistance (Inner)	4 milliohms maximum
Engagement/Disengagement Force	≤0.12N.m
Connection Torque	0.6N·m - 0.8N·m
Adaptation Pin	φ0.38mm, φ0.51mm

Key Benefits for Your Applications

Reliable Connection Performance

Our connectors ensure consistent signal transmission, minimal loss, and excellent electrical performance across all frequencies, with low VSWR for optimal signal integrity in critical applications.

Mechanical Durability

These SSMA Detachable Connectors endure up to 500 mating cycles, maintaining performance and reliability even in demanding environments with repeated connections and robust construction.

Environmental Resilience

Our connectors meet stringent military standards for environmental testing:

Thermal shock resistance (MIL-STD-202, Method 107, Condition B)
Salt spray protection (MIL-STD-202, Method 101, Condition B)
Vibration resistance (MIL-STD-202, Method 204, Condition D)
Shock resistance (MIL-STD-202, Method 213, Condition I)
Moisture resistance (MIL-STD-202, Method 106)

product-1-1

Perfect for Multiple Industries

Telecommunications

These connectors excel in telecom applications where space is premium. You get reliable high-frequency performance in compact equipment designs.

Aerospace and Defense

Military-grade environmental compliance makes our connectors suitable for aerospace applications. They perform reliably in extreme conditions.

Medical Equipment

The precision manufacturing and reliable performance meet medical industry standards. You can trust these connectors in critical medical devices.

Test and Measurement

Laboratory equipment benefits from the excellent signal integrity and repeatability. These connectors provide consistent results for accurate measurements.

product-1-1

Why Choose Shaanxi Chuangyu Electronic Technology?

We specialize in precision electrical connectors with over 200 specifications of millimeter wave connectors. Our facility in Xi'an combines advanced manufacturing with rigorous quality control. You receive products that meet international standards while supporting domestic innovation.Our engineering team provides comprehensive support from design to delivery.

We get it your challenges and offer arrangements that work. Each item experiences strict testing to guarantee unwavering quality from generation through end-use.

product-1-1

Custom Arrangements Available

Need particular arrangements? We offer customization administrations for one of a kind prerequisites. Our building group works with you to create connectors that meet your correct details.

From size modifications to special pin configurations, we deliver solutions that fit your needs.

Get Started Today

Ready to boost your project with high-performance solutions? Contact our technical team to discuss your needs and find the ideal SSMA Detachable Connector configuration for your success.Email us at postmaster@cymicrowave.com for technical specifications, pricing, or custom development discussions.

Trust Shaanxi Chuangyu Electronic Technology for reliable, high-quality miniature RF connector solutions that deliver performance when it matters most.
