Name: 1.85 RF Attenuator
SKU: N/A

1.85 RF Attenuator

1. The fixed attenuator for 1.85mm RF connectors serves as a passive component in RF systems, designed to reduce signal power.
2. It is used in high-frequency systems such as microwave communications and test measurements, requiring compatibility with 67GHz.
3. Attenuation values (e.g., 1dB/3dB/10dB/40dB, etc.), power handling capacity of 2W.
4. Impedance: 50 Ohms nominal
5. Frequency range: DC to 67GHz
6. VSWR: 1.5:1 to 67GHz typical
7. Power: 2W
8. Attenuation value: 40dB
9. Attenuation accuracy: ±1.5dB
10. Temperature range: -55°C to 125°C

1.85 RF Attenuator - High-Frequency Signal Control Solution

Are you looking for precise signal control in your high-frequency applications? Our 1.85 RF Attenuator delivers exceptional performance for microwave communications and test measurement systems. This passive component provides reliable signal power reduction while maintaining signal integrity across demanding frequency ranges. Whether you're working with research facility gear or field applications, this item guarantees steady comes about up to 67GHz. Built for proficient utilize, it combines vigorous development with exact constriction capabilities to meet your most challenging RF requirements

What Makes Our RF Attenuator Special?

Our settled attenuator highlights stainless steel lodging for strength and electromagnetic protecting, with beryllium copper gold center contacts for prevalent execution. The wide temperature extend of -55°C to 125°C and PEI insulin guarantee solid operation in unforgiving situations over the whole recurrence spectrum.

The 50-ohm impedance matches standard RF frameworks flawlessly. You won't require extra coordinating systems or connectors. This spares time and diminishes potential flag misfortunes in your setup.

product-1-1

Technical Specifications

General Specifications
Product Name	1.85JKS-67-2W-40dB Attenuator
Impedance	50 Ohms nominal
Frequency Range	DC to 67 GHz
Temperature Range	-55°C to 125°C
Electrical Performance
---------------------------	---
VSWR	1.5:1 to 67GHz typical
Attenuation Value	40dB
Attenuation Accuracy	±1.5dB
Power Rating	2W
Materials & Construction
---------------------------	---
Housing	Stainless Steel Passivated
Center Contacts	Beryllium Copper Gold
Insulators	PEI
Mechanical Properties
---------------------------	---
Mate/Demate Cycles	500 cycles
Engagement Force	≤0.23N.m
Connection Torque	0.8N·m - 1.1N·m
Withstand Torque	1.2N·m
Environmental Standards
---------------------------	---
Thermal Shock	MIL-STD-202, Method 107, Condition B
Salt Spray	MIL-STD-202, Method 101, Condition B
Vibration	MIL-STD-202, Method 204, Condition D
Shock	MIL-STD-202, Method 213, Condition I
Moisture Resistance	MIL-STD-202, Method 106

Key Applications

Test and Measurement Systems

Your laboratory equipment needs precise signal control. Our attenuator provides stable 40dB attenuation with ±1.5dB accuracy. This ensures repeatable measurements across your frequency range.

Microwave Communications

Communication systems require careful power management. The 1.85 RF Attenuator with 2W power handling capability supports various signal levels. You can use it for transmitter output control or receiver input protection.

Research and Development

Development work demands reliable components. The 500 mate/demate cycles support frequent connections. This reduces replacement costs and maintains project schedules.

Military and Aerospace

Defense applications need components that withstand extreme conditions. Our attenuator meets multiple MIL-STD specifications. It performs consistently in challenging environments.

product-1-1

Why Choose Our Product?

Precision Designing: Each unit experiences thorough testing to guarantee determination compliance. Our quality control handle ensures steady execution over generation batches.

Extended Recurrence Run: The DC to 67GHz capability covers most advanced applications. You won't require different components for diverse recurrence bands.

Robust Development: Military-grade materials and development procedures guarantee long benefit life. The passivated stainless steel lodging stands up to erosion and wear.

Easy Integration: Standard 1.85mm connectors give compatibility with existing frameworks. Establishment requires negligible time and exertion.

product-1-1

Installation and Usage Tips

Use specified torque values to connect the attenuator, ensuring proper contact without damaging threads. Monitor operating temperature to maintain accuracy and component life. Handle connectors carefully, especially the 1.85mm interface, to preserve alignment and precision.

Store unused units in protective packaging. This prevents contamination and mechanical damage to the connector interfaces.

About Shaanxi Chuangyu Electronic Technology

We specialize in precision RF components and test solutions, with cutting-edge products developed in Xi'an. Our experienced engineering team designs reliable, high-performance solutions for demanding applications, ensuring consistent results through quality manufacturing processes.

Customer satisfaction guides our development efforts. We listen to your feedback and incorporate improvements into new designs. This collaborative approach delivers products that meet your specific needs.

Get Your Product Today

Ready to improve your system performance? Our 1.85 RF Attenuator provides the precision and reliability you need. Contact our technical team to discuss your requirements. We offer customization options, including different attenuation values and specifications, with engineering support to optimize the solution for your needs.

For technical questions or ordering information, reach out to us at postmaster@cymicrowave.com. Our team provides prompt responses and expert guidance for your project requirements.
